| Number of extensions |
1 hydraulic |
2 hydraulic |
3 hydraulic |
| Crane Rating (ft. lbs.) |
18,700 |
18,700 |
18,700 |
| Max. Horizontal Reach – hydraulic |
14’11” |
19’8″ |
24’3″ |
| Max. Vertical Reach – hydraulic |
22’11” |
27’4″ |
31’8″ |
| Max. Capacity (lbs.) |
1260 |
890 |
660 |
| Crane Weight (lbs.) |
1000 |
1080 |
1150 |
| Crane Dimensions |
82″ x 63″ x 20″ |
82″ x 63″ x 20″ |
82″ x 63″ x 20″ |
| Mounting Space |
5’5″ x 5’3″ x 1’7″ |
5’5″ x 5’3″ x 1’7″ |
5’5″ x 5’3″ x 1’7″ |
| Slewing Angle |
370 |
370 |
370 |
| Oil Tank Capacity (gallons) |
6.6 |
6.6 |
6.6 |
| Max. Oil Flow (gpm) |
2.1 |
2.1 |
2.1 |
| Max. Working Pressure (psi) |
2538 |
2538 |
2538 |
| Stabilizers Manual Out |
8’1″ |
8’1″ |
8’1″ |
